Android Custom GridView Example Using Kotlin

1. Creating New Project in Kotlin

• Open Android Studio.
• Go to File => New => New Project.Give Name To your application. Then, check Include Kotlin Support and click next button.
• Select minimum SDK you need. However, we have selected 21 as minimum SDK. Then, click next button.
• Then, select Empty Activity => click next => click finish.

2. For Custom GridView We need two XML file main xml file contain GridView and Other Contain a Single Item which we want to Show in GridView.Here we Have Two XML file

1. main_activity.xml
2. grid_item.xml

main_activity.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    xmlns:tools="http://schemas.android.com/tools"
    android:layout_width="match_parent"
    android:layout_height="match_parent"
    tools:context="com.dharmendra.customgridview.MainActivity">

   <GridView
       android:id="@+id/gridView"
       android:numColumns="2"
       android:layout_width="match_parent"
       android:layout_height="match_parent"/>
</RelativeLayout>

grid_item.xml

<?xml version="1.0" encoding="utf-8"?>
<RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android"
    xmlns:app="http://schemas.android.com/apk/res-auto"
    android:layout_width="match_parent" android:layout_height="match_parent">

    <ImageView
        android:id="@+id/imageView"
        android:layout_width="100dp"
        android:layout_height="100dp"
        android:layout_alignParentStart="true"
        android:layout_alignParentTop="true"
        android:layout_marginStart="28dp"
        android:layout_marginTop="26dp"/>

    <TextView
        android:id="@+id/textView"
        android:layout_width="wrap_content"
        android:layout_height="wrap_content"
        android:layout_alignEnd="@+id/imageView"
        android:layout_alignStart="@+id/imageView"
        android:layout_below="@+id/imageView"
        android:layout_centerVertical="true"
        android:layout_marginTop="11dp"
        android:gravity="center"
        android:layout_centerHorizontal="true"
        android:textColor="@android:color/black"
        android:textSize="16sp" />
</RelativeLayout>

We add some Image to res/drawable to display in GridView

3. MainActivity.kt

package com.dharmendra.customgridview

import android.os.Bundle
import android.support.v7.app.AppCompatActivity
import android.widget.GridView
import android.widget.Toast

class MainActivity : AppCompatActivity() {

    override fun onCreate(savedInstanceState: Bundle?) {
        super.onCreate(savedInstanceState)
        setContentView(R.layout.activity_main)

        //Find View By Id For GridView
        val gridView = findViewById<GridView>(R.id.gridView) as GridView

        /*Create and ArrayList of Integer Type To Store Images From drawable.Here we add Images to ArrayList.
        We have Images of Android Icons of Different versions.
        */

        val arrayListImage = ArrayList<Int>()

        arrayListImage.add(R.drawable.cupcake)
        arrayListImage.add(R.drawable.donut)
        arrayListImage.add(R.drawable.eclair)
        arrayListImage.add(R.drawable.froyo)
        arrayListImage.add(R.drawable.gingerbread)
        arrayListImage.add(R.drawable.honeycomb)
        arrayListImage.add(R.drawable.icecreamsandwich)
        arrayListImage.add(R.drawable.jellybean)
        arrayListImage.add(R.drawable.kitkat)
        arrayListImage.add(R.drawable.lollipop)
        arrayListImage.add(R.drawable.marshmallow)
        arrayListImage.add(R.drawable.nougat)
        arrayListImage.add(R.drawable.oreo)


        // Here We take and Array of Android OS names in Same Sequence as we take Images.

        val name = arrayOf("Cupcake", "Donut", "Eclair", "Froyo", "Gingerbread", "Honeycomb", "Icecreamsandwich",
                "Jellybean", "Kitkat", "Lollipop", "Marshmallow", "Nougat", "Oreo")


        //We Have Created Custom Adapter Class in that we pass Context,ArrayList of Image and Array Of name

        val customAdapter = CustomAdapter(this@MainActivity, arrayListImage, name)

        //Set Adapter to ArrayList

        gridView.adapter = customAdapter

        //On Click for GridView Item

        gridView.setOnItemClickListener { adapterView, parent, position, l ->
            Toast.makeText(this@MainActivity, "Click on : " + name[position], Toast.LENGTH_LONG).show()
        }

    }


}

4. Now We have to Create Class CustomAdapter.Right Click on Package name---->New--->Kotlin File/Class.

Now Select Class in Kind and Add name of Class.Here Our Class name is CustomAdapter.

5. After Class is Created add parameter to Class(passed in Main Activity) and extend with BaseAdapter()

Ex:

class CustomAdapter(context: Context, arrayListImage: ArrayList<Int>, name: Array<String>

) : BaseAdapter() {

..

..

..

}

You will get Some Error Put Your Cursor on Red line And Press Alt+Enter and click on Implement Members and Select All Methods and click Ok.

CustomAdapter.kt

package com.dharmendra.customgridview

import android.app.Activity
import android.content.Context
import android.view.View
import android.view.ViewGroup
import android.widget.BaseAdapter
import android.widget.ImageView
import android.widget.TextView

/**
 * Created by root on 3/23/18.
 */
/*We Have Created Constructor of Custom Adapter and Pass
                context
                ArrayList<Int> which Contain images
                Array which contain name*/

//Here We extend over Adapter With BaseAdapter()


class CustomAdapter(context: Context, arrayListImage: ArrayList<Int>, name: Array<String>) : BaseAdapter() {

    //Passing Values to Local Variables

    var context = context
    var arrayListImage = arrayListImage
    var name = name


    //Auto Generated Method
    override fun getView(position: Int, convertView: View?, parent: ViewGroup?): View {

        var myView = convertView
        var holder: ViewHolder


        if (myView == null) {

            //If our View is Null than we Inflater view using Layout Inflater

            val mInflater = (context as Activity).layoutInflater

            //Inflating our grid_item.
            myView = mInflater.inflate(R.layout.grid_item, parent, false)

            //Create Object of ViewHolder Class and set our View to it

            holder = ViewHolder()


            //Find view By Id For all our Widget taken in grid_item.

            /*Here !! are use for non-null asserted two prevent From null.
             you can also use Only Safe (?.)

            */


            holder.mImageView = myView!!.findViewById<ImageView>(R.id.imageView) as ImageView
            holder.mTextView = myView!!.findViewById<TextView>(R.id.textView) as TextView

            //Set A Tag to Identify our view.
            myView.setTag(holder)


        } else {

            //If Our View in not Null than Just get View using Tag and pass to holder Object.

            holder = myView.getTag() as ViewHolder

        }

        //Setting Image to ImageView by position
        holder.mImageView!!.setImageResource(arrayListImage.get(position))

        //Setting name to TextView by position
        holder.mTextView!!.setText(name.get(position))

        return myView

    }

    //Auto Generated Method
    override fun getItem(p0: Int): Any {
        return arrayListImage.get(p0)
    }

    //Auto Generated Method
    override fun getItemId(p0: Int): Long {
        return 0
    }

    //Auto Generated Method
    override fun getCount(): Int {
        return arrayListImage.size
    }


    //Create A class To hold over View like we taken in grid_item.xml

    class ViewHolder {

        var mImageView: ImageView? = null
        var mTextView: TextView? = null

    }

}

Output:
